Description:
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS™ Bypass Technology
INPUT Nominal Input Voltage (Vac): 230
Input Voltage Range (Vac): 160 ~ 263
Input Frequency (Hz): 50 ± 3 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current (A): 10
Input Connector Type: IEC C14 Detachable
Power Cord Plug Type: IEC C14/AU
Power Cord Length (ft.): 6
Power Cord Length (m.): 1.83
OUTPUT Capacity (VA): 600
Capacity (Watts): 360
On Battery Waveform: Simulated Sine Wave On
Battery Voltage(s) (Vac): 230 ± 10% On Battery Frequency (Hz): 50 ± 1% 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost
Overload Protection: Internal Current Limiting, Circuit Breaker Outlet(s)
– Total: 6 Outlet Type: IEC C13 x6 Outlet(s)
- Battery & Surge Protected: 4
USB Charging Port(s): 2
Typical Transfer Time (ms): 4
BATTERY Runtime at Half Load (min): 13
Runtime at Full Load (min): 4 Typical
Recharge Time (Hours): 8
Start on Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Type: Sealed Lead-acid Replacement
Battery Pack: RBP0019 RBP
Quantity (pcs): 1 SURGE PROTECTION & FILTERING
Surge Suppression (Joules): 405 EMI/RFI
Filtration: Yes
Phone/Network Protection RJ11/RJ45(1GB) (Combo): 1-in, 1-out PHYSICAL
Form Factor: Rack Rackmount
Ears: Yes
PHYSICAL SIZE – UPS MODULE Dimensions (WxHxD) (in.): 17.0 x 1.7 x 9.3 Dimensions (WxHxD) (mm.): 433 x 44 x 235 Weight (lbs.):17.2 Weight (kg.): 7.8
